Hydraulic Flow Control Valve Speed Regulating Valve STB-G3/ 4 One-way Throttle Valve
Description
Bi-Directional flow restrictor hydraulic valve, also called check valve, is used in hydraulic system to control the flow and cutoff of oil.
If the oil inlet and outlet of a straight through check valve are in a axial direction, the valve may be connected directly to the system pipe via threaded pipe fittings.
The opening pressure of check valve may be either 0.04MPa or 0.4MPa. The former is normally used in pressure pipes to prevent oil from flowing in reverse direction, while the latter may be normally used as a back pressure valve.
Application
The flow control valves are able to produce a pressure drop between inlet and outlet. They are not pressure compensated so the regulated flow can change infunction of the pressure and of the viscosity.
Dimension and specification
| Model | Max Flow
L/min | Max pressure
MPA | C | L | H | D | E | F | G | N | PN |
| STB-G1/4 | 12 | 40 | G1/4 | 54 | 72 | 32 | 20 | M20*1 | 5 | 7 | 40 |
| STB-G3/8 | 30 | 40 | G3/8 | 62 | 80 | 32 | 25 | M25*1.5 | 9 | 7 | 40 |
| STB-G1/2 | 50 | 40 | G1/2 | 73 | 92 | 45 | 30 | M20*1.5 | 9 | 9 | 40 |
| STB-G3/4 | 85 | 40 | G3/4 | 84 | 100 | 45 | 40 | M35*1.5 | 10 | 11 | 40 |
| STB-G1 | 150 | 32 | G1 | 102 | 122 | 45 | 45 | M40*1.5 | 12 | 15 | 32 |
Product show
Note
Please don't work more than indicated pressure range.
Samples
You can send a sample to customize the products, we have many engineers can help it; If you want a product of mine, but you are not sure if it's what you want, so you can ask for a sample from me, it will be free.
Quality Standards
The company for the products are brand new original products, no second-hand and refurbished products, or leave a compensable ten and return the full amount, but the buyer due to our purchase of model error is not responsible for returns, another of the company's sales of products enjoy one year from the date of shipment quality assurance, according to the original quality standards, during warranty with product problems, need confirmation testing by the manufacturer, the supplier to be solved, the demand side due to storage, use, poor maintenance caused by lower-quality product, and not raise objections.
Packaging shipping
1. If order is not big enough, we will provide Door To Door service, we cooperate with UPS,DHL,FEDEX,TNT all year round,we gurantee that the shipping price that we offer to you is the most favorable price among so many suppliers in China.
2. By Air or By Sea through your forwarder is acceptable, if you have no forwarder in China, we also could find you cost-effective forwarder for your reference.
After-sale service
We can provide a series of after-sale service, such as product introduction, mounting, debugging, technical support and so on.
