FESTO ISO cylinder DSBC-50-300-PPVA-N3 2098975 GTIN4052568251406 Pneumatic Air Cylinders

  • 1
  • 2
  • 3

Brand Name : FESTO

Model Number : DSBC-40-200-PPVA-N3

Place of Origin : China

MOQ : 1pc

Price : EXW USD100-120

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 50 pcs per month

Delivery Time : 10-15 working days

Packaging Details : plastic bag, carton，OPP bag

Brand : FESTO

Type : DSBC-40-200-PPVA-N3

Part no : 2098975

GTIN : 4052568251406

Piston rod thread : M16x1.5

Conforms to standard : ISO 15552

Contact Now

FESTO ISO cylinder DSBC-50-300-PPVA-N3 2098975 GTIN4052568251406 Pneumatic Air Cylinders

About product

1.Super durable, stable performance.

2.Environmentally friendly materials.

3.Small and portable, smart buffering, saving adjustment time, one year warranty

4.Long service life.

5.Complete variety to meet various needs.

Technical Data

Stroke 300mm
Piston diameter 50 mm
Piston rod thread M16x1.5
Cushioning Pneumatic cushioning, adjustable at both ends
Mounting position optional
Conforms to standard ISO 15552
Piston-rod end Male thread
Design Piston Piston rod Profile barrel
Position detection Via proximity switch
Symbol 00991235
Variants Piston rod at one end
Mode of operation Double-acting
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -20°C-80°C
Cushioning length 22 mm
Basic weight for 0 mm stroke 1190 g
Additional weight per 10 mm stroke 56g
Type of mounting Via female thread With accessories Either:
Pneumatic connection G1/4
Note on materials RoHS-compliant
Material cover Die-cast aluminium, coated
Material piston seal TPE-U(PU)
Material piston Wrought aluminium alloy
Material piston rod High-alloy steel
Material piston rod wiper TPE-U(PU)
Buffer seal material TPE-U(PU)
Cushioning piston material POM
Material cylinder barrel Smooth-anodised wrought aluminium alloy
Material nut Galvanised steel
Material bearing POM
Material collar screws Galvanised steel


Another stroke as follow

Type Order no GTIN Price
DSBC-50-20-PPVA-N3 2098969 4052568251352 USD100-120
DSBC-50-25-PPVA-N3 1366948 4052568231101 USD100-120
DSBC-50-30-PPVA-N3 2098970 4052568251369 USD100-120
DSBC-50-40-PPVA-N3 1366949 4052568231118 USD100-120
DSBC-50-50-PPVA-N3 1366950 4052568231125 USD100-120
DSBC-50-60-PPVA-N3 2098972 4052568251376 USD100-120
DSBC-50-70-PPVA-N3 2098973 4052568251383 USD100-120
DSBC-50-80-PPVA-N3 1366951 4052568016463 USD100-120
DSBC-50-100-PPVA-N3 1366952 4052568016470 USD100-120
DSBC-50-125-PPVA-N3 1366953 4052568016487 USD100-120
DSBC-50-150-PPVA-N3 2098974 4052568251390 USD100-120
DSBC-50-160-PPVA-N3 1366954 4052568016494 USD100-120
DSBC-50-200-PPVA-N3 1366955 4052568016500 USD100-120
DSBC-50-250-PPVA-N3 1366956 4052568016517 USD100-120
DSBC-50-300-PPVA-N3 2098975 4052568251406 USD100-120
DSBC-50-320-PPVA-N3 1366957 4052568016524 USD100-120
DSBC-50-400-PPVA-N3 1366958 4052568016531 USD100-120
DSBC-50-500-PPVA-N3 1366959 4052568231132 USD100-120

Application examples

FESTO ISO cylinder DSBC-50-300-PPVA-N3 2098975 GTIN4052568251406 Pneumatic Air Cylinders

Festo continuously improves the manufacturing level through innovative and optimized motion control solutions, and provides automated manufacturing and processing equipment with higher performance and higher profits.

There are so many kinds. Hurry to call me!
