FESTO Pneumatic Solenoid Valves VMPA2-M1BH-M-PI 8022034 GTIN4052568257309

  • 1
  • 2
  • 3

Brand Name : FESTO

Model Number : VMPA2-M1BH-M-PI

Place of Origin : China

MOQ : 1pc

Price : EXW USD60-80

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 300 pcs per month

Delivery Time : 5-7 working days

Packaging Details : Plastic bag, Carton

Order no : 8022034

Model : VMPA2-M1BH-M-PI

Brand : FESTO

Product weight : 100 g

Material housing : Die-cast aluminium

Note on materials : RoHS-compliant

Contact Now

FESTO Solenoid valve VMPA2-M1BH-M-PI 8022034 GTIN4052568257309

About product

1.High pressure range :–0.09 ... +1 MPa .

2.Wide range of valve functions.

3.Secure wall mounting.

4.MPA2 (width 20 mm).

Advantage

1.Easy to service thanks to replaceable valves and electronic modules .

2.Manual override either non-detenting, detenting or secured against unauthorised activation (concealed).

3.Fast troubleshooting thanks to LEDs on the valves .

4.Extensive operating voltage range ±25%.

5.Compact high-performance valves in sturdy metal housing.

6.The valves are identical to the valves in the valve terminal MPA-S and MPA-L. This simplifies planning, ordering and warehousing.

Technical Data

Valve function 5/2-way, monostable
Type of actuation Electric
Valve size 20 mm
Standard nominal flow rate 870 l/min
Operating voltage 24V DC
Operating pressure -0.09 MPa ... 1 MPa
Operating pressure -0.9 bar ... 10 bar
Design Piston gate valve
Type of reset Pneumatic spring
Approval c UL us - Recognized (OL)
Degree of protection IP65 To IEC 60529
Sealing principle Soft
Mounting position optional
Manual override Detenting Non-detenting
Type of piloting Pilot actuated
Flow direction Reversible
Symbol 00991050
lap Positive overlap
Signal status display yes
Pilot pressure 0.3 MPa ... 0.8 MPa
Pilot pressure 3 bar ... 8 bar
Suitability for vacuum yes
Standard nominal flow rate with QS-10 870 l/min
Switching time off 28 ms
Switching time on 15 ms
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Corrosion resistance class CRC 1 - Low corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Max. tightening torque for valve mounting 0.65 Nm
Product weight 100 g
Type of mounting With through-hole
Note on materials RoHS-compliant
Material seals NBR
Material housing Die-cast aluminium

Picture about packages

FESTO Pneumatic Solenoid Valves VMPA2-M1BH-M-PI 8022034 GTIN4052568257309

There are so many products, welcome to enquire!
